Hand-operated trolley in combination with the REMA Select 200OD hand chain hoist.
Only available in combination with the REMA Select 200 OD manual chain hoist.


Properties

  • Extremely low building height (135-235 mm).
  • Suitable for beams with both straight and sloping flange.
  • Maintenance-free ball bearings.
  • Wheel rupture supports for extra safety.
  • Hand chain operated trolley.
  • Technical specifications for manual hoist see Select 200 OD chain hoist.

Standard delivery

  • 3 meters lifting height (max. between top and bottom hook).
  • 2.5 meters operation.

Option

  • Available in other lifting and operating heights.
  • Marking: CE-marked
Select a row from the table below, then click the add to cart button
Part Code WLL
ton
Model Flange width
mm
Load Chain dia x pitch
mm
Hand Chain dia x pitch
mm
Chain falls Min. curve radius
mm
A
mm
B1
mm
B2
mm
C1
mm
C2
mm
D1
mm
D2
mm
E1

mm
E2

mm
F
mm
H
mm
L
mm
M1
mm
M2
mm
Weight
kg
CAD
0923001 1 KBT200OD-1 74-150 5.0 X 15 5.0 X 23.7 2 2,500 554 206 234 129 151 117 223 217 134 27.5 135 348 40 18 69
0923003 2 KBT200OD-2 82-156 6.3 X 19.1 5.0 X 23.7 2 4,000 684 254 406 149 211 165 265 240 152 36.5 160 392 50 24 118
0923005 3.2 KBT200OD-3.2 103-223 8.0 X 24.2 5.0 X 23.7 2 4,500 765 279 461 169 236 165 325 240 173 44 190 499 55 28 181
0923007 5 KBT200OD-5 119-215 8.0 X 24.2 5.0 X 23.7 4 6,000 873 336 524 201 279 184 327 259 180 39 235 512 65 37 293
0923009 6.3 KBT200OD-6.3 119-215 8.0 X 24.2 5.0 X 23.7 4 6,000 873 336 524 201 279 184 327 259 180 39 235 512 65 37 296

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
