The THEIPA Point-F internal thread attachment swivel is a ball-bearing lifting attachment point for industrial load handling. It is used where a swivel connection with internal thread is required, helping maintain correct load alignment while reducing the risk of link kinking through its crimped link design.
Best used for:
- Swiveling lifting points with internal thread connection.
- Applications requiring galvanized corrosion protection.
Product benefits:
- Ball bearing supports controlled swivel movement under load.
- Crimped link helps prevent kinking during handling.
- Galvanized coating provides corrosion protection.
- Multiple thread sizes support different load requirements.
- RFID chip option supports digital identification.
Different threaded versions and lengths can be supplied on request.
- Material: Eye and swivel of alloy
- Marking: CE-marked, UKCA-marked, WLL.
- Temperature range: -40° up to +400°C
- Finish: Painted.
- Safety factor: 4:1
