Type description

  • Type C811 has a safety coefficient 5 in all loading directions.
  • Type C812 has a safety coefficient 4 in all loading directions.
  • Marking: According to standard, CE-marked
  • Standard: EN 1677-1
  • Note: Rotatable through 360°, foldable 90°.
  • Warning: Not rotatable under load.
  • Safety factor: 4
  • Grade: 10
Select a row from the table below, then click the add to cart button
Part Code Code WLL Thread
mm
Model A
mm
B
mm
C
mm
E
mm
F
mm
G
mm
H
mm
M
mm
L
mm
SW
mm
SWI
mm
Weight CAD
2611308 8717365176135 0.3 M8 C811X-M8x12-0.3T 33,5 56 30 40 14 28 99 M8 12 13 5 0.38
2611310 8717365176142 0.6 M10 C811X-M10x15-0.6T 34,5 56 30 40 14 28 99 M10 15 17 6 0.38
2611312 8717365176159 1 M12 C811X-M12x18-1.0T 35,5 56 30 40 14 28 99 M12 18 19 7 0.38
2611314 8717365176166 1.3 M14 C811X-M14x21-1.3T 46 74,5 47 55 18 38 135,5 M14 21 22 7 1.3
2611316 8717365176173 1.6 M16 C811X-M16x25-1.6T 46,5 74,5 47 55 18 38 135,5 M16 25 24 10 1.3
2611318 8717365176180 2 M18 C811X-M18x27-2.0T 47 74,5 47 55 18 38 135,5 M18 27 27 10 1.3
2611320 8717365176197 2.5 M20 C811X-M20x30-2.5T 43 79 45 55 25 38 138 M20 30 24 10 1.3
2611322 8717365176203 3 M22 C811X-M22x33-3.0T 63,5 106 62 84 25 56 198,5 M22 33 32 12 4
2611324 8717365176210 4 M24 C811X-M24x36-4.0T 64,5 106 62 84 25 56 198,5 M24 36 36 14 4
2611327 8717365176227 5 M27 C811X-M27x40-5.0T 66,5 106 62 84 25 56 198,5 M27 40 41 14 4
2611330 8717365176234 6.3 M30 C811X-M30x45-6.3T 68 106 62 84 25 56 198,5 M30 45 46 17 4
2611336 8717365176241 10 M36 C812X-M36x54-10T 80 150 76,5 108 32 85 220 M36 54 - 17 6
2611342 8717365176258 12.5 M42 C812X-M42x63-12.5T 80 150 76,5 108 32 85 220 M42 63 - 17 6
2611348 8717365176265 17 M48 C812X-M48x68-17T 90 176 95 128 39 100 257 M48 68 - 17 10.5
2611356 8717365176272 25 M56 C812X-M56x78-25T 90 176 95 126 39 100 257 M56 78 - 17 16.3
2611364 8717365176289 35 M64 C812X-M64x90-35T 105 200 110 126 46 113 277 M64 90 - 19 16.3
