Intended for attaching of wire rope where switching often occur, e.g. blocks of mobilecranes, or to be able to adjust the length of the wire rope. See recommended assembly to get correct results.
The wedge socket is delivered complete with wedge, pin and cotterpin.

2 surface finishes available:

  • Model OWS P : blue painted.
  • Model OWS PGALV : Hot dipped galvanized.
  • Material: Quenched and tempered cast steel
  • Marking: CE-marked
  • Temperature range: - 40°C to + 110°C - Use at higher temperatures possible with reduction of WLL.
  • Finish: Blue painting or hot dipped galvanized
  • Note: The efficiency of a 6 and 8 strand wire rope/wedge socket connection is 80% of the minimum breaking load of the wire but limited to the minimum breaking load of the socket (MBL).
Select a row from the table below, then click the add to quote button
Part Code MBL For wire Ø
mm
A
mm
B
mm
C
mm
øP
mm
T
mm
TL
mm
TB
mm
W
mm
Weight CAD
10.20OWS.25P 8 7-8 110 18 36 16 9 128 51 18 0.8
10.20OWS.25PGALV 8 7-8 110 18 36 16 9 128 51 18 0.8
10.20OWS.5P 12 9-10 145 23 46 21 11 168 63 21 1.7
10.20OWS.5PGALV 12 9-10 145 23 46 21 11 168 63 21 1.7
10.20OWS1P 20 11-13 157 29 57 25 12 185 67 25 2.1
10.20OWS1PGALV 20 11-13 157 29 57 25 12 185 67 25 2.1
10.20OWS2P 25 14-16 190 35 70 30 15 225 85 31 4
10.20OWS2PGALV 25 14-16 190 35 70 30 15 225 85 31 4
10.20OWS3P 40 18-19 210 40 80 35 16 250 95 38 7
10.20OWS3PGALV 40 18-19 210 40 80 35 16 250 95 38 7
10.20OWS4P 55 20-22 252 48 95 41 18 300 110 44 10
10.20OWS4PGALV 55 20-22 252 48 95 41 18 300 110 44 10
10.20OWS5P 75 23-26 298 55 110 51 22 353 128 51 15
10.20OWS5PGALV 75 23-26 298 55 110 51 22 353 128 51 15
10.20OWS6P 90 27-29 322 65 130 57 25 387 142 57 21
10.20OWS6PGALV 90 27-29 322 65 130 57 25 387 142 57 21
10.20OWS7P 110 30-32 350 73 146 63 28 423 155 63 31
10.20OWS7PGALV 110 30-32 350 73 146 63 28 423 155 63 31
10.20OWS8P 125 34-36 400 74 148 64 28 474 160 70 37
10.20OWS8PGALV 125 34-36 400 74 148 64 28 474 160 70 37
10.20OWS9P 150 37-39 450 80 142 70 30 530 177 77 51
10.20OWS9PGALV 150 37-39 450 80 142 70 30 530 177 77 51
10.20OWS10P 170 40-42 500 87 160 76 33 587 187 76 64
10.20OWS10PGALV 170 40-42 500 87 160 76 33 587 187 76 64
10.20OWS11P 225 43-48 550 100 186 89 39 650 215 89 96
10.20OWS11PGALV 225 43-48 550 100 186 89 39 650 215 89 96
10.20OWS12P 280 49-52 637 105 205 95 46 740 244 101 130
10.20OWS12PGALV 280 49-52 637 105 205 95 46 740 244 101 130
10.20OWS13P 360 54-58 660 125 250 108 54 785 275 114 180
10.20OWS13PGALV 360 54-58 660 125 250 108 54 785 275 114 180
10.20OWS14P 425 60-68 835 135 270 121 60 970 300 127 275
10.20OWS14PGALV 425 60-68 835 135 270 121 60 970 300 127 275
10.20OWS15P 460 72-76 1,000 150 300 133 76 1,150 355 146 440
10.20OWS15PGALV 460 72-76 1,000 150 300 133 76 1,150 355 146 440
10.20OWS16P 625 81-86 1,160 150 300 140 79 1,310 375 159 510
10.20OWS16PGALV 625 81-86 1,160 150 300 140 79 1,310 375 159 510
