The REMA X-Line hand chain hoist is a robust and ergonomic hoist for intensive use.

Properties

  • Low operating force at full load.
  • Increased operational safety due to double pawl system.
  • Brake is provided with astbestos free friction discs.
  • Load chain wheel is made of wear-resistant alloy steel.
  • Top and bottom hook have safety latches.
  • In case of overload, the hooks will gradually bend and do not suddenly break off.
  • Galvanized load chain (Grade 8).
  • Galvanized hand chain.
  • Steel housing with orange colored powder coating.

Standard delivery

  • 3 meters lifting height (max. between top and bottom hook).
  • 2.5 meters operating height.

Option

  • Available in any other hoisting and operational heights.

Norm:

  • EN12100-1/2, EN13157, EN818-7
  • Marking: According to standard, CE-marked
  • Standard: EN 13157, EN 818-7
Select a row from the table below, then click the add to cart button
Part Code Code WLL
kg
Lifting height
m
Model Load Chain dia x pitch
mm
Hand Chain dia x pitch
mm
Chain falls Construction height
mm
Hand force max.
kg
A
mm
B
mm
C
mm
D
mm
H
mm
Weight
kg
CAD
0170000-3 8717365112539 0.25 3 X-CH/250KG/3M 4.0 x 12 5.0 x 23.7 1 260 23.5 108 106 20 30 260 6
0170000-4 8717365112423 0.25 4 X-CH/250KG/4M 4.0 x 12 5.0 x 23.7 1 260 23.5 108 106 20 30 260 7.4
0170000-5 8717365112430 0.25 5 X-CH/250KG/5M 4.0 x 12 5.0 x 23.7 1 260 23.5 108 106 20 30 260 8.8
0170000-6 8717365112553 0.25 6 X-CH/250KG/6M 4.0 x 12 5.0 x 23.7 1 260 23.5 108 106 20 30 260 10.2
0170000-7 8717365112447 0.25 7 X-CH/250KG/7M 4.0 x 12 5.0 x 23.7 1 260 23.5 108 106 20 30 260 11.6
0170000-8 8717365112454 0.25 8 X-CH/250KG/8M 4.0 x 12 5.0 x 23.7 1 260 23.5 108 106 20 30 260 13
0170000-9 8717365112461 0.25 9 X-CH/250KG/9M 4.0 x 12 5.0 x 23.7 1 260 23.5 108 106 20 30 260 14.4
0170000-10 8717365112478 0.25 10 X-CH/250KG/10M 4.0 x 12 5.0 x 23.7 1 260 23.5 108 106 20 30 260 15.8
0170001-3 8717365096211 0.5 3 X-CH/500KG/3M 5.0 x 15 5.0 x 23.7 1 280 24.9 130 128 22 34 280 10
0170001-4 8717365096440 0.5 4 X-CH/500KG/4M 5.0 x 15 5.0 x 23.7 1 280 24.9 130 128 22 34 280 11.6
0170001-5 8717365096457 0.5 5 X-CH/500KG/5M 5.0 x 15 5.0 x 23.7 1 280 24.9 130 128 22 34 280 13.2
0170001-6 8717365096228 0.5 6 X-CH/500KG/6M 5.0 x 15 5.0 x 23.7 1 280 24.9 130 128 22 34 280 14.8
0170001-7 8717365096464 0.5 7 X-CH/500KG/7M 5.0 x 15 5.0 x 23.7 1 280 24.9 130 128 22 34 280 16.4
0170001-8 8717365096471 0.5 8 X-CH/500KG/8M 5.0 x 15 5.0 x 23.7 1 280 24.9 130 128 22 34 280 18
0170001-9 8717365096488 0.5 9 X-CH/500KG/9M 5.0 x 15 5.0 x 23.7 1 280 24.9 130 128 22 34 280 19.6
0170001-10 8717365096495 0.5 10 X-CH/500KG/10M 5.0 x 15 5.0 x 23.7 1 280 24.9 130 128 22 34 280 21.2
0170003-3 8717365096235 1 3 X-CH/1000KG/3M 6.3 x 19 5.0 x 23.7 1 330 28.4 150 142 26 39 330 12
0170003-4 8717365096501 1 4 X-CH/1000KG/4M 6.3 x 19 5.0 x 23.7 1 330 28.4 150 142 26 39 330 13.9
0170003-5 8717365096518 1 5 X-CH/1000KG/5M 6.3 x 19 5.0 x 23.7 1 330 28.4 150 142 26 39 330 15.8
0170003-6 8717365096242 1 6 X-CH/1000KG/6M 6.3 x 19 5.0 x 23.7 1 330 28.4 150 142 26 39 330 17.7
0170003-7 8717365096525 1 7 X-CH/1000KG/7M 6.3 x 19 5.0 x 23.7 1 330 28.4 150 142 26 39 330 19.6
0170003-8 8717365096532 1 8 X-CH/1000KG/8M 6.3 x 19 5.0 x 23.7 1 330 28.4 150 142 26 39 330 21.5
0170003-9 8717365096549 1 9 X-CH/1000KG/9M 6.3 x 19 5.0 x 23.7 1 330 28.4 150 142 26 39 330 23.4
0170003-10 8717365096556 1 10 X-CH/1000KG/10M 6.3 x 19 5.0 x 23.7 1 330 28.4 150 142 26 39 330 25.3
0170005-3 8717365096259 1.5 3 X-CH/1500KG/3M 7.1 x 21 5.0 x 23.7 1 360 30.8 170 158 29 42 360 16
0170005-4 8717365096563 1.5 4 X-CH/1500KG/4M 7.1 x 21 5.0 x 23.7 1 360 30.8 170 158 29 42 360 18.2
0170005-5 8717365096570 1.5 5 X-CH/1500KG/5M 7.1 x 21 5.0 x 23.7 1 360 30.8 170 158 29 42 360 20.4
0170005-6 8717365096266 1.5 6 X-CH/1500KG/6M 7.1 x 21 5.0 x 23.7 1 360 30.8 170 158 29 42 360 22.6
0170005-7 8717365096587 1.5 7 X-CH/1500KG/7M 7.1 x 21 5.0 x 23.7 1 360 30.8 170 158 29 42 360 24.8
0170005-8 8717365096594 1.5 8 X-CH/1500KG/8M 7.1 x 21 5.0 x 23.7 1 360 30.8 170 158 29 42 360 27
0170005-9 8717365096600 1.5 9 X-CH/1500KG/9M 7.1 x 21 5.0 x 23.7 1 360 30.8 170 158 29 42 360 29.2
0170005-10 8717365096617 1.5 10 X-CH/1500KG/10M 7.1 x 21 5.0 x 23.7 1 360 30.8 170 158 29 42 360 31.4
0170007-3 8717365096273 2 3 X-CH/2000KG/3M 8.0 x 24 5.0 x 23.7 1 385 34.3 185 175 35 49 385 20
0170007-4 8717365096624 2 4 X-CH/2000KG/4M 8.0 x 24 5.0 x 23.7 1 385 34.3 185 175 35 49 385 22.4
0170007-5 8717365096631 2 5 X-CH/2000KG/5M 8.0 x 24 5.0 x 23.7 1 385 34.3 185 175 35 49 385 24.8
0170007-6 8717365096280 2 6 X-CH/2000KG/6M 8.0 x 24 5.0 x 23.7 1 385 34.3 185 175 35 49 385 27.2
0170007-7 8717365096648 2 7 X-CH/2000KG/7M 8.0 x 24 5.0 x 23.7 1 385 34.3 185 175 35 49 385 29.6
0170007-8 8717365096655 2 8 X-CH/2000KG/8M 8.0 x 24 5.0 x 23.7 1 385 34.3 185 175 35 49 385 32
0170007-9 8717365096662 2 9 X-CH/2000KG/9M 8.0 x 24 5.0 x 23.7 1 385 34.3 185 175 35 49 385 34.4
0170007-10 8717365096679 2 10 X-CH/2000KG/10M 8.0 x 24 5.0 x 23.7 1 385 34.3 185 175 35 49 385 36.8
0170009-3 8717365096297 3 3 X-CH/3000KG/3M 7.1 x 21 5.0 x 23.7 2 510 34.3 220 158 37 50 510 26
0170009-4 8717365096686 3 4 X-CH/3000KG/4M 7.1 x 21 5.0 x 23.7 2 510 34.3 220 158 37 50 510 29.4
0170009-5 8717365096693 3 5 X-CH/3000KG/5M 7.1 x 21 5.0 x 23.7 2 510 34.3 220 158 37 50 510 32.8
0170009-6 8717365096303 3 6 X-CH/3000KG/6M 7.1 x 21 5.0 x 23.7 2 510 34.3 220 158 37 50 510 36.2
0170009-7 8717365096709 3 7 X-CH/3000KG/7M 7.1 x 21 5.0 x 23.7 2 510 34.3 220 158 37 50 510 39.6
0170009-8 8717365096716 3 8 X-CH/3000KG/8M 7.1 x 21 5.0 x 23.7 2 510 34.3 220 158 37 50 510 43
0170009-9 8717365096723 3 9 X-CH/3000KG/9M 7.1 x 21 5.0 x 23.7 2 510 34.3 220 158 37 50 510 46.4
0170009-10 8717365096730 3 10 X-CH/3000KG/10M 7.1 x 21 5.0 x 23.7 2 510 34.3 220 158 37 50 510 49.8
0170011-3 8717365096310 5 3 X-CH/5000KG/3M 9.0 x 27 5.0 x 23.7 2 615 37.2 255 183 43 60 615 41.5
0170011-4 8717365096747 5 4 X-CH/5000KG/4M 9.0 x 27 5.0 x 23.7 2 615 37.2 255 183 43 60 615 46
0170011-5 8717365096754 5 5 X-CH/5000KG/5M 9.0 x 27 5.0 x 23.7 2 615 37.2 255 183 43 60 615 50.5
0170011-6 8717365096327 5 6 X-CH/5000KG/6M 9.0 x 27 5.0 x 23.7 2 615 37.2 255 183 43 60 615 55
0170011-7 8717365096761 5 7 X-CH/5000KG/7M 9.0 x 27 5.0 x 23.7 2 615 37.2 255 183 43 60 615 59.5
0170011-8 8717365096778 5 8 X-CH/5000KG/8M 9.0 x 27 5.0 x 23.7 2 615 37.2 255 183 43 60 615 64
0170011-9 8717365096785 5 9 X-CH/5000KG/9M 9.0 x 27 5.0 x 23.7 2 615 37.2 255 183 43 60 615 68.5
0170011-10 8717365096792 5 10 X-CH/5000KG/10M 9.0 x 27 5.0 x 23.7 2 615 37.2 255 183 43 60 615 73
0170015-3 8717365096433 10 3 X-CH/10000KG/3M 9.0 x 27 5.0 x 23.7 4 820 40 360 183 47 65 820 75
0170015-4 8717365096808 10 4 X-CH/10000KG/4M 9.0 x 27 5.0 x 23.7 4 820 40 360 183 47 65 820 83
0170015-5 8717365096815 10 5 X-CH/10000KG/5M 9.0 x 27 5.0 x 23.7 4 820 40 360 183 47 65 820 91
0170015-6 8717365096426 10 6 X-CH/10000KG/6M 9.0 x 27 5.0 x 23.7 4 820 40 360 183 47 65 820 99
0170015-7 8717365096822 10 7 X-CH/10000KG/7M 9.0 x 27 5.0 x 23.7 4 820 40 360 183 47 65 820 107
0170015-8 8717365096839 10 8 X-CH/10000KG/8M 9.0 x 27 5.0 x 23.7 4 820 40 360 183 47 65 820 115
0170015-9 8717365096846 10 9 X-CH/10000KG/9M 9.0 x 27 5.0 x 23.7 4 820 40 360 183 47 65 820 123
0170015-10 8717365096853 10 10 X-CH/10000KG/10M 9.0 x 27 5.0 x 23.7 4 820 40 360 183 47 65 820 131

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
