• Marking: According to standard, CE-marked
  • Standard: EN 1677-3
  • Safety factor: 4
  • Grade: 10
Select a row from the table below, then click the add to cart button
Part Code Code WLL Size Model P
mm
D
mm
E
mm
T
mm
H
mm
O
mm
W
mm
Weight CAD
2645006 8717365116568 1.4 6 RES-6MM 107.6 11.3 20.8 15.1 22.3 28 72 0.5
2645008 8717365116575 2.5 8 RES-8MM 135.4 12.1 27.2 20.2 25.7 35.5 89.5 0.8
2645010 8717365116582 4 10 RES-10MM 165 15.6 33.8 26.4 30 45 107.2 1.4
2645013 8717365116599 6.7 13 RES-13MM 202 20.5 40 32.2 41.8 51 138.8 2.9
2645016 8717365116605 10 16 RES-16MM 250 27.3 49.6 38.3 50 60 170 5.6
